Technical Specification

Description	Unit	NR - 149	NR - 149 4F
Max Job Length	mm	2440	1200
Min. Job Length	mm	300	300
Job Thickness Range	mm	16-125	16-125
Min. Job Width	mm	150	150
Max Heating Temp	c	200	200
Compressed Air Requirement	Kg-cm²	7	7
Heating Element	Kw	3	2
Electric Motor - 3Phase	HP	0.5	0.5

Silent Features

Automatic Post forming cycle.
Pneumatic cylinders to apply uniform pressure on job for effective bonding of Laminates.
Facility for manual and Automatic
Hard chrome plated heater bar for smooth operation and long life.
Mechanical drive control.
Drive motor with brake is provided to avoid slippage of rotary part.

Nihar Industries is synonymous with wood crafting machineries. We excel in manufacturing machineries required in wood Cutting, Polishing, Pressing, Fabrication and Engraving.
